Will a 98+ 4L60E work in a older truck? (96-97)

This is a discussion on Will a 98+ 4L60E work in a older truck? (96-97) within the Performance forums, part of the General Discussion category; I got a built 4L60E for sale and I have several people asking me what would need to be done ...

  1. #1
    Registered User
    Join Date
    Oct 2001
    Location
    Moreno Valley, Calif.
    Age
    57
    Posts
    568

    Will a 98+ 4L60E work in a older truck? (96-97)


    Support FSC and see no ads! - Click Here
    I got a built 4L60E for sale and I have several people asking me what would need to be done to it for it to work in an older truck 96-97 year model. Also what would be needed to install say in a Camaro or Firebird? I know they make six different bolt on bell housings and tail shafts housings for it...

    Came out of a 1999 2WD Tahoe 5.7L

    http://www.fullsizechevy.com/forums/...d.php?t=148619

    Thanks for any help guys!

    Ken
    1996 K1500, Built 4340 forged 383 Engine, SRP 8.9 comp. Vortech V1-S-trim SC, 7.3L turbo diesel intercooler, BBK, Thorleys, Crower 401LM, Crower roller rockers 1.5, Custom ported big valve vortec heads, TunerCat Edit Programing, 4.10 gears, BFG 33's www.kctrading.net/sierra

  2. #2
    Registered User
    Join Date
    Apr 2003
    Location
    Bakersfield
    Age
    32
    Posts
    424

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Ken, it seems to me that if it came out of a 99 5.7 (traditional small block) then it would fit the 96-97's also. I am not positive on this as I am not a tranny guy, but if its true, then I am interested, and could pick it up next week from you as I'm under two hours away. My tranny isn't dead yet, but with 123,000 on it, and behind 400 hp I'm not sure how long it will last. If it wasn't for the aux. tranny cooler I'm sure it would be dead by now!
    97 Silverado ECSB 383, ported vortec heads, LT4 Hot Cam Kit, Vmax Spacer, Ed Wright tuning, Thorley headers,Vig 2800 Converter, Duals w/ X-pipe and Magnaflows - 330.5 RWHP, 381.1 RWTQ unlocked w/ stock poppet injectors- 13.632 @ 98.94 w/ 1.90 60'

  3. #3
    H2 recovery team BRIDGEZ71's Avatar
    Join Date
    Mar 2004
    Location
    GEORGIA
    Age
    34
    Posts
    886

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    should bolt right up to another 2wd(96-99) truck.
    4wd conversion would require different tailshaft housing and ouput shaft
    camaro/similar cars probably would need bellhousing swap along with tailshaft housing and output shaft.either way it can be "reused" for several applications.
    CHEVY TECH PART TIME
    REDNECK FULL TIME
    99z-71 5.3 4.10 ...

  4. #4
    Home of the Snooki punch! CKTA's Avatar
    Join Date
    Aug 2001
    Location
    New Jersey
    Age
    39
    Posts
    54,510

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Quote Originally Posted by BRIDGEZ71
    should bolt right up to another 2wd(96-99) truck.

    4wd conversion would require different tailshaft housing and ouput shaft

    camaro/similar cars probably would need bellhousing swap along with tailshaft housing and output shaft.either way it can be "reused" for several applications.




    I'm not 100% sure the bellhousings are different tho.
    2015 Carlisle All Truck Nats info..
    http://www.fullsizechevy.com/forum/o...t-7th-9th.html


  5. #5
    RIP Pop, 5th AAC WWII tdrumm's Avatar
    Join Date
    Mar 2003
    Location
    Northeast NJ
    Age
    36
    Posts
    1,457

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Bellhousings are different from a traditional small block to a genIII.
    RIP Billy, aka budhayes 3


  6. #6
    Home of the Snooki punch! CKTA's Avatar
    Join Date
    Aug 2001
    Location
    New Jersey
    Age
    39
    Posts
    54,510

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Quote Originally Posted by tdrumm
    Bellhousings are different from a traditional small block to a genIII.
    True, but he does'nt mention what year F-body. It will bolt up to the LT1 correct?
    2015 Carlisle All Truck Nats info..
    http://www.fullsizechevy.com/forum/o...t-7th-9th.html


  7. #7
    Beaner/Cracker Izzy's Avatar
    Join Date
    Aug 2001
    Location
    Fort Worth, TX
    Age
    34
    Posts
    8,939

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    I would imagine the harness could be different although I put in a 97 tranny in the wifes 98 and the stock harness worked with the new tranny.

  8. #8
    gasaholic/fuel addict
    Join Date
    Dec 2004
    Location
    Benton Arkansas
    Posts
    27

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    you might want to double check but i think the valve bodies are different. I think. call your local tranny specialist. check this link trans ?
    93' 1500 rcsb 4.3 (flat tops, 30 over, cam, full roller, MSD, e fans, KnN, ram air, 4l60E w/shift kit, 3.42 locking diff. and an air freshener)

  9. #9
    lateral G junkie wkdspd's Avatar
    Join Date
    Nov 2001
    Location
    Plano, TX
    Age
    39
    Posts
    2,135

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    I just went through this entire setup on the current project the trans you have will work on any truck 96+. wiring is also the same. the f-body versions have different bellhousings (LS1) and different tailshafts. starters will also be different depending on bellhousing.

  10. #10
    Home of the Snooki punch! CKTA's Avatar
    Join Date
    Aug 2001
    Location
    New Jersey
    Age
    39
    Posts
    54,510

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Quote Originally Posted by wkdspd
    I just went through this entire setup on the current project the trans you have will work on any truck 96+. wiring is also the same. the f-body versions have different bellhousings (LS1) and different tailshafts. starters will also be different depending on bellhousing.

    What about the LT1's?
    2015 Carlisle All Truck Nats info..
    http://www.fullsizechevy.com/forum/o...t-7th-9th.html


  11. #11
    Original Gold Member SLMDLT1's Avatar
    Join Date
    Nov 2001
    Location
    Gainesville, Florida
    Age
    29
    Posts
    2,768

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    It will bolt up to an LT1. I used my original 96 truck tranny for awhile on my lt1 before I opted to have one built up.
    2003 GMC Sierra ECSB Z71...6-7.5" Superlift, 20" Eagle 064s on 37x13.50x20 Kumho MT's, Predator, etc.
    1998 Chevrolet Camaro Z28, LS1/M6/C5's/SPEC/Lid/LT'S/MAGNAFLOW

  12. #12
    Home of the Snooki punch! CKTA's Avatar
    Join Date
    Aug 2001
    Location
    New Jersey
    Age
    39
    Posts
    54,510

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    That's what i thought.
    2015 Carlisle All Truck Nats info..
    http://www.fullsizechevy.com/forum/o...t-7th-9th.html


  13. #13
    white and nerdy
    Join Date
    Apr 2002
    Location
    Dallas, Tx
    Age
    28
    Posts
    7,061

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Great thread
    2002 Tahoe
    le malibu

    Currently seeking - suburban

  14. #14
    lateral G junkie wkdspd's Avatar
    Join Date
    Nov 2001
    Location
    Plano, TX
    Age
    39
    Posts
    2,135

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Quote Originally Posted by SLMDLT1
    It will bolt up to an LT1.
    from what I understand, yes, and he confirms it - I have only played with swaps on the LS, but it makes sense since the LT motors are built off the same outer profile as the standard 350, while the LS motor is the newer profile.
    Last edited by wkdspd; 03-16-2005 at 01:35 PM.

  15. #15
    Insecure fat kid DemoN's Avatar
    Join Date
    Jan 2002
    Location
    San Antonio, TX
    Age
    40
    Posts
    18,495

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    Quote Originally Posted by wkdspd
    I just went through this entire setup on the current project the trans you have will work on any truck 96+. wiring is also the same. the f-body versions have different bellhousings (LS1) and different tailshafts. starters will also be different depending on bellhousing.
    glad i brought over that extra tranny? :LOL:

  16. #16
    Observationalist James B.'s Avatar
    Join Date
    Dec 2001
    Location
    33.91 -117.48
    Age
    40
    Posts
    1,362

    Re: Will a 98+ 4L60E work in a older truck? (96-97)

    The input shaft on this transmission is 30-spline. Gen-III and LSx engines use a version with a 33-spline input shaft. Torque converters between the two different designs are not interchangable. 4.3/5.0/5.7L Vortec and LT1 versions are all 30-spline.
    "James B." '99LT_Tahoe4Dr2WD, Tuned L29 Vortec 454, 62#Injectors, MSD6A, Six 3"mufflers, 10.5"non-float14bolt ,EatonPosi, 4.56:1, Built4L80E, Gear_Vendors, Splined_Driveshaft, HydroBoost, Be-Cool_Rad., FAL-292fans, Tracbars, Swaybars, AirRide, etc.
